Hydrogen Water Generator

Product

Hydrogen-Rich Water Generator

Model

Hydrogen Machine

Installation Method

Directly Connected to RO Water purifier(DCR Type) by Booster Pump & Solenoid control to Electrolyzer Installation: Counter top only(not under-sink type)

Dimension

323 x 145 x 280 (H,D,W)mm

Net Weight

3.65 kg

Gross Weight

4.5 kg

Power

Input : AC 100-240 V/50-60Hz/ Output(P/Adapter):
DC 24V/5A

Operating Temperature

5-50°C(41-100°F)- indoor usage only

Operating Water Pressure

input: 1.0-5.0Kgf/cm2(14-74 psi)

Outflow Rate

1 Liter per minute

Power Consumption

Adapter : 120W, (Electrolyzer power consumption : 72W - 24V / 3A)

Extra Filter
pH Enhancer Filter :

Specification/Feature:

Outer Dimension(mm): D 48 x H 140
Filter Media: Bio+ ceramic Ball (NSF)

Life Time:

2000 Liters (approx)

Other Function :
Auto-Stop function

 If input water is not pumped into the product for 10 seconds, the HydroGen will stop automatically to protect the electrolyzer and all-electric circuit. It applies to all modes.

Electrolyzer Cleaning Mode:

To extend Electrolyzer lifetime/performance, cleaning mode is needed twice a week or every 70 liters usage.

P/Adapter & Pump :

P/Adapter Power: DC 24V 5A, Booster Pump: DC24V 0.6A
